Lung differentiation¶
The direct lung differentiation dataset from Hurley, K. et al. Cell Stem Cell (2020) doi:10.1016/j.stem.2019.12.009.
This dataset has multiple time points for the state manifold, but only one time point for the clonal observation on day 27.
[1]:
import cospar as cs
import numpy as np
[2]:
cs.logging.print_version()
cs.settings.verbosity = 2
cs.settings.data_path = "lung_data_paper" # A relative path to save data. If not existed before, create a new one.
cs.settings.figure_path = "lung_figure_paper" # A relative path to save figures. If not existed before, create a new one.
cs.settings.set_figure_params(
format="png", dpi=75, fontsize=14
) # use png to reduce file size.
Running cospar 0.2.0 (python 3.8.12) on 2022-02-07 22:07.
Load data¶
[3]:
adata_orig = cs.datasets.lung()
[4]:
adata_orig
[4]:
AnnData object with n_obs × n_vars = 15832 × 26766
obs: 'time_info', 'state_info'
uns: 'clonal_time_points', 'data_des', 'state_info_colors'
obsm: 'X_clone', 'X_emb', 'X_pca'
Preprocessing (optional)¶
[5]:
preprocessing = False
if preprocessing:
cs.pp.get_highly_variable_genes(
adata_orig,
normalized_counts_per_cell=10000,
min_counts=3,
min_cells=3,
min_gene_vscore_pctl=80,
)
cs.pp.remove_cell_cycle_correlated_genes(
adata_orig, corr_threshold=0.03, confirm_change=False
) # optional step
cs.pp.get_X_pca(adata_orig, n_pca_comp=40)
# cs.pp.get_X_umap(adata_orig,n_neighbors=20,umap_min_dist=0.3) # we want to keep the original embedding
# cs.pp.get_state_info(adata_orig,leiden_resolution=0.5) # we want to keep the original state annotation
[6]:
cs.pl.embedding(adata_orig, color="state_info")
[7]:
cs.hf.check_available_choices(adata_orig)
Available transition maps: []
Available clusters: ['NLE', 'Endoderm', 'PNEC', 'Gut', 'iAEC2', 'Others']
Available time points: ['D27' 'pos_17' 'pos_21']
Clonal time points: ['D27']
Basic clonal analysis¶
[8]:
cs.pl.clones_on_manifold(
adata_orig,
selected_clone_list=[30, 198, 150, 58, 263],
color_list=["blue", "red"],
selected_times=["D27"],
)
[9]:
cs.tl.fate_coupling(
adata_orig,
source="X_clone",
selected_fates=["iAEC2", "PNEC", "Gut", "NLE", "Endoderm"],
)
cs.pl.fate_coupling(adata_orig, source="X_clone")
WARNING: ['Endoderm'] are ignored due to lack of cells
Results saved as dictionary at adata.uns['fate_coupling_X_clone']
[9]:
<AxesSubplot:title={'center':'source: X_clone'}>
[10]:
cs.pl.barcode_heatmap(
adata_orig,
selected_times="D27",
selected_fates=["iAEC2", "PNEC", "Gut", "NLE", "Endoderm"],
binarize=True,
)
Data saved at adata.uns['barcode_heatmap']
[10]:
<AxesSubplot:>
[11]:
cs.tl.clonal_fate_bias(adata_orig, selected_fate="iAEC2", alternative="two-sided")
cs.pl.clonal_fate_bias(adata_orig)
100%|██████████| 272/272 [00:00<00:00, 616.34it/s]
Data saved at adata.uns['clonal_fate_bias']
Infer transition map from end-point clones¶
It takes around 9 minutes to run it for the first time (the data has ~15000 cells). Later runs take < 3 mins.
[12]:
initial_time_points = ["pos_17", "pos_21"]
clonal_time_point = "D27"
adata = cs.tmap.infer_Tmap_from_one_time_clones(
adata_orig,
initial_time_points=["pos_17", "pos_21"],
later_time_point="D27",
initialize_method="HighVar",
HighVar_gene_pctl=80,
max_iter_N=[1, 3],
smooth_array=[20, 15, 10],
sparsity_threshold=0.2,
)
Trying to set attribute `.uns` of view, copying.
Trying to set attribute `.uns` of view, copying.
--------Infer transition map between initial time points and the later time one-------
--------Current initial time point: pos_17--------
Step 0: Pre-processing and sub-sampling cells-------
Step 1: Use the HighVar method for initialization-------
Step a: find the commonly shared highly variable genes------
Highly varable gene number: 3689 (t1); 3729 (t2). Common set: 1075
Step b: convert the shared highly variable genes into clonal info------
Total used genes=863 (no cells left)
Step c: compute the transition map based on clonal info from highly variable genes------
Load pre-computed similarity matrix
Iteration 1, Use smooth_round=20
Iteration 2, Use smooth_round=15
Iteration 3, Use smooth_round=10
Convergence (CoSpar, iter_N=3): corr(previous_T, current_T)=0.923
Finishing initialization using HighVar, used time 75.68489861488342
Step 2: Jointly optimize the transition map and the initial clonal states-------
-----JointOpt Iteration 1: Infer initial clonal structure
-----JointOpt Iteration 1: Update the transition map by CoSpar
Load pre-computed similarity matrix
Iteration 1, Use smooth_round=20
Iteration 2, Use smooth_round=15
Iteration 3, Use smooth_round=10
Convergence (CoSpar, iter_N=3): corr(previous_T, current_T)=0.959
Convergence (JointOpt, iter_N=1): corr(previous_T, current_T)=0.413
Finishing Joint Optimization, used time 28.069818019866943
Trying to set attribute `.uns` of view, copying.
--------Current initial time point: pos_21--------
Step 0: Pre-processing and sub-sampling cells-------
Step 1: Use the HighVar method for initialization-------
Step a: find the commonly shared highly variable genes------
Highly varable gene number: 3794 (t1); 3729 (t2). Common set: 1152
Step b: convert the shared highly variable genes into clonal info------
Total used genes=1088 (no cells left)
Step c: compute the transition map based on clonal info from highly variable genes------
Load pre-computed similarity matrix
Iteration 1, Use smooth_round=20
Iteration 2, Use smooth_round=15
Iteration 3, Use smooth_round=10
Convergence (CoSpar, iter_N=3): corr(previous_T, current_T)=0.939
Finishing initialization using HighVar, used time 80.7336368560791
Step 2: Jointly optimize the transition map and the initial clonal states-------
-----JointOpt Iteration 1: Infer initial clonal structure
-----JointOpt Iteration 1: Update the transition map by CoSpar
Load pre-computed similarity matrix
Iteration 1, Use smooth_round=20
Iteration 2, Use smooth_round=15
Iteration 3, Use smooth_round=10
Convergence (CoSpar, iter_N=3): corr(previous_T, current_T)=0.982
Convergence (JointOpt, iter_N=1): corr(previous_T, current_T)=0.823
Finishing Joint Optimization, used time 29.09626293182373
-----------Total used time: 219.88412308692932 s ------------
Save pre-computed map¶
[13]:
save_data = False
if save_data:
cs.hf.save_map(adata)
# adata=cs.hf.read('lung_data_paper/Lung_OneTimeClone_t*pos_17*pos_21*D27_adata_with_transition_map.h5ad')
Plotting¶
[14]:
cs.tl.fate_map(adata, source="transition_map", map_backward=True)
cs.pl.fate_map(
adata, selected_fates=["iAEC2"], source="transition_map", plot_target_state=True
)
Results saved at adata.obs['fate_map_transition_map_NLE']
Results saved at adata.obs['fate_map_transition_map_Endoderm']
Results saved at adata.obs['fate_map_transition_map_PNEC']
Results saved at adata.obs['fate_map_transition_map_Gut']
Results saved at adata.obs['fate_map_transition_map_iAEC2']
Results saved at adata.obs['fate_map_transition_map_Others']
[15]:
# cs.settings.set_figure_params(figsize=(4,3.5),format='png',fontsize=17)
selected_fates = ["iAEC2", ["PNEC", "Gut", "NLE", "Endoderm"]]
cs.tl.fate_bias(
adata, selected_fates, source="transition_map", map_backward=True, method="norm-sum"
)
cs.pl.fate_bias(
adata,
selected_fates=selected_fates,
source="transition_map",
plot_target_state=False,
background=False,
show_histogram=True,
)
Results saved at adata.obs['fate_map_transition_map_iAEC2']
Results saved at adata.obs['fate_map_transition_map_PNEC_Gut_NLE_Endoderm']
Results saved at adata.obs['fate_bias_transition_map_iAEC2*PNEC_Gut_NLE_Endoderm']
DGE analysis¶
[16]:
selected_fates = ["iAEC2", ["PNEC", "Gut", "NLE", "Endoderm"]]
cs.tl.progenitor(
adata,
selected_fates,
source="transition_map",
sum_fate_prob_thresh=0,
bias_threshold_A=0.6,
bias_threshold_B=0.3,
)
cs.pl.progenitor(
adata, selected_fates, source="transition_map", selected_times=["pos_17"]
)
Results saved at adata.obs['fate_map_transition_map_iAEC2']
Results saved at adata.obs['fate_map_transition_map_PNEC_Gut_NLE_Endoderm']
Results saved at adata.obs['fate_bias_transition_map_iAEC2*PNEC_Gut_NLE_Endoderm']
Results saved at adata.obs[f'progenitor_transition_map_iAEC2'] and adata.obs[f'diff_trajectory_transition_map_iAEC2']
Results saved at adata.obs[f'progenitor_transition_map_PNEC_Gut_NLE_Endoderm'] and adata.obs[f'diff_trajectory_transition_map_PNEC_Gut_NLE_Endoderm']
[17]:
import numpy as np
cell_group_A = np.array(adata.obs["progenitor_transition_map_iAEC2"])
cell_group_B = np.array(adata.obs["progenitor_transition_map_PNEC_Gut_NLE_Endoderm"])
dge_gene_A, dge_gene_B = cs.tl.differential_genes(
adata, cell_group_A=cell_group_A, cell_group_B=cell_group_B, FDR_cutoff=0.05
)
[18]:
selected_genes = dge_gene_A["gene"][:2]
cs.pl.gene_expression_on_manifold(
adata, selected_genes=selected_genes, color_bar=True, savefig=False
)
Update cluster annotation
[19]:
state_info = np.array(adata.obs["state_info"]).astype(">U15")
state_info[cell_group_A > 0] = "iAEC2 prog."
state_info[cell_group_B > 0] = "Non-iAEC2 prog."
adata.obs["state_info"] = state_info
[20]:
cs.settings.set_figure_params(fontsize=10)
state_info = np.array(adata.obs["state_info"])
gene_list = [
"KLF9",
"CEBPD",
"YBX3",
"ATF4",
"NKX2-1",
"IRX3",
"SLC7A11",
"LIFR", #'HSPA5',
"SFRP1",
"CD55",
"KIT",
"CPM", #'LDLR', 'GFRA1',
"PITX1",
"MSX2",
"MYCN",
"SOX9",
"SOX11",
"ID2",
"PBX1",
"FOXA1",
"SP5",
"TMPO",
"DEK",
"HMGB1",
"PARP1",
] # , 'TFDP1', 'HNRNPD', 'MYBL2']
selected_fates = ["iAEC2 prog.", "Non-iAEC2 prog."]
renames = ["iAEC2 prog.", "Non-iAEC2 prog."]
gene_expression_matrix = cs.pl.gene_expression_heatmap(
adata,
selected_genes=gene_list,
selected_fates=selected_fates,
rename_fates=renames,
horizontal=True,
fig_width=6.5,
fig_height=2,
)
